Computer Controlled Tensile Testing Machine – BONAD Universal Testing Machine
Standards
Our tensile testing machine adheres to international standards including ASTM D903, CNS11888, JIS K6854, PSTC7, ASTM D638, and ISO527. These standards ensure the reliability and accuracy of test results across various applications.
Applications
This machine is engineered to evaluate the mechanical properties of materials under diverse conditions such as tension, compression, bending, shearing, tearing, peeling, and puncture. It is an essential tool for quality inspection and material analysis across multiple industries.
Features
- Precision Measurement: Equipped with imported force sensors and photoelectric encoders to ensure accurate force and displacement readings.
- Advanced Control System: Utilizes an embedded single-chip microcomputer structure with comprehensive measurement and control software that integrates measurement, control, calculation, and storage functions.
- Automated Calculations: Capable of automatically calculating stress, elongation (with extensometer), tensile strength, elastic modulus; it also records maximum point force values or elongation automatically.
- Dynamic Display: The computer interface dynamically displays the test process and curves while processing data efficiently.
- Data Analysis Tools: Post-test features include curve enlargement through a graphic processing module for detailed data analysis and editing; reports can be generated easily.
- International Standard Performance: This machine’s performance meets international advanced levels in terms of precision and functionality.
Technical parameters:
| Equipment model | BND-CTM01 | BND-CTM02 |
| Model | Single column type | Dual column type (gantry type) |
| Test capacity | Any choice within the range of 0-500kg | Any choice within the range of 0-5000kg |
| Control motor | Servo motor | |
| Test speed | Adjustable from 0.1-500mm/min | |
| Force unit | Kg, Lb, N switching function | |
| Test stroke | 600/800mm | 800/1000 mm |
| Control method | High-precision computer control software (curve graph) | |
| Test fixture | Standard universal fixture set (please note if special requirements are required) | |
Computer Controlled Tensile Testing Machine – Single Column Type:
Computer Controlled Tensile Testing Machine – Dual Column Type:
