The nozzle of the test equipment is made of brass, and the handle is made of SUS304# stainless steel, which is not only beautiful but also very durable. At the same time, the equipment is a handheld device, and the tester can perform waterproof tests on the test samples from any angle. The test water pressure can also be freely adjusted according to the test requirements. It is a very good IPX3&IPX4 waterproof test equipment.
Features of the test equipment:
- The mirror of the nozzle is 78 degrees, with 121 holes with a diameter of 0.5mm. The number, diameter and angle of the holes are manufactured in full accordance with the standard.
- Accurate water flow calculation, using an electronic flow meter to record the test values, the obtained values are clearer and easier to understand.
- The waterproof test level and test water pressure can be adjusted.
Test equipment technical parameters:
| Number of holes | Total 121 |
| Diameter of nozzle holes | 0.5 mm |
| Material | Spray nozzle made of brass |
| Pressure gauge | 0 ~ 0.25Mpa |
| Water discharge | 10L/min, ±5%, can adjustment |
| Reference | IEC60529 IPX3 IPX4, IEC60598-1, IEC 60335-1, IEC60745-1 |
| Nozzle diameter | 102 mm |
| Nozzle hole surface radian | 78° |
Note:
When the baffle covers 1/3 of the nozzle, it is IPX3 waterproof test; when there is no baffle covering, it is IPX4 waterproof test.
