BS1363 Figure 5 Gauge For Plug Pins

The gauge shall be deemed to meet the dimensional requirements (if the measurement results are within thespecified dimension and the measurement uncertainty does not exceed 0.005mm when the confidence level does not exceed 95%)

12.2.1 lnspection, measurement and use of gauge as shown in Figure 5. For gauge test, the reconnecting plugshould be connected with BS 6500:2000, 1.25mm2 3-core flexible cord as shown in Table 27. Non-reconnectingplugs shall be tested in delivery condition.
