BONAD Vertical Composite Salt Spray Test Chamber – Ultimate Corrosion Testing Solution
Standards:
Our salt spray test chamber adheres to international standards such as:
- ASTM B117
- ISO 9227
- JIS Z 2371
- DIN 50021
These standards ensure reliable and consistent testing results.
Features:
-
Vertical Design:
- Space-efficient structure suitable for laboratories or production lines.
-
Composite Salt Spray Testing:
- Beyond conventional tests like ASTM B117, it simulates additional corrosive environments such as acid rain and chloride conditions.
-
Temperature Control System:
- Precisely controls the temperature within the chamber to meet diverse testing requirements.
-
Humidity Control:
- Adjusts humidity levels to mimic real-world environmental changes.
-
Automation Control:
- Advanced touch screen interface for easy operation and parameter monitoring.
-
Data Recording and Analysis:
- Real-time data recording with detailed reporting capabilities for subsequent analysis.
-
Safety Protection Features:
- Equipped with over-temperature protection and water level monitoring to ensure safety for both equipment and users.
Applications:
The Vertical Composite Salt Spray Test Chamber is designed to simulate marine climate conditions for assessing material performance against salt spray corrosion. It evaluates the protective layer’s process quality on products such as automotive parts, electroplating items, coatings, electronic components, and industrial products’ metal protective layers.
Technical parameters:
| Specification | Details |
|---|---|
| Model | BND-VCSS |
| Chamber Dimensions (LxWxH) mm | 1000 x 1000 x 1000 |
| Overall Dimensions (LxWxH) mm | 2580 x 1450 x 1400 |
| Volume (L) | 1000 L |
| Saltwater Tank Capacity | 100 L |
| Test Chamber Temperature | 10℃ – 80℃ |
| Test Chamber Humidity | 20% – 100% RH |
| Pressure Vessel Temperature | RT + 10℃ ~ 80℃ |
| pH Value | “pH = 6.5 ~ 7.2 (NSS) / pH = 3.0 ~ 3.1 (ACSS, CASS) before collection pH = 6.5 ~ 7.2 (NSS) / pH = 3.1 ~ 3.3 (ACSS, CASS) after collection” |
| Saltwater Concentration | “Sodium Chloride Solution Concentration: 5% (Neutral Salt Spray) Sodium Chloride Solution Concentration: 5% + Glacial Acetic Acid (Acetic Salt Spray) Sodium Chloride Solution Concentration: 5% + Glacial Acetic Acid + 0.26g Copper Chloride (Copper Accelerated Salt Spray)” |
| Temperature Uniformity | +1℃ |
| Temperature Fluctuation | ±0.5℃ |
| Spraying Method | Continuous Spray + Intermittent Spray |
| Operating Modes | Salt Spray, Wetting, Drying, Condensation, Sprinkling (optional), can be combined in any cycle mode or operated individually |
| Control Method | 7-inch LCD Touch Screen Controller |
| Communication Method | RS232/USB/Ethernet port, any two communication options |
| Power | 12 KW |
| Power Supply | AC380V, 50HZ |
| Door Opening Method | Front-opening door, single opening |
