IEC60529 IP5X IP6X Sand and Dust Proof Test Chamber

Brand: SZBONAD

Product Number: BND-IP56X

The sand and dust proof test chamber is mainly used for IP5X and IP6X sand and dust proof tests, and the equipment complies with IEC60529 standards. The equipment simulates environmental conditions such as dust and sand, and conducts physical and other related performance tests on electronic and electrical products, lamps, electrical cabinets, electrical components, automobiles, motorcycles and their parts to verify whether the product performance meets the requirements.

GET A QUOTE

The outer layer of the sand and dust proof test box is made of high-quality steel plate, which is not only beautiful but also resistant to dirt and corrosion. It is also equipped with an extra-large window for easy observation of the internal test conditions. There are also a variety of automatic settings, such as temperature control table and box door protection device, which ensure the safety of the operator while making the sand and dust proof test box more durable.

IEC60529 IP5X IP6X Sand and Dust Proof Test Chamber

Features of sand and dust prevention test equipment:

  1. A variety of arbitrary setting control functions adopt 7-inch touch screen + Panasonic PLC, with full Chinese display, which can display year, month, day, time, working time, etc. The dust blower, dust vibration and total test time can be controlled separately.

IEC60529 IP5X IP6X Sand and Dust Proof Test Chamber-1

  1. Sealing ring protection: rubber sealing ring is used on the door edge to prevent dust from floating out.

IEC60529 IP5X IP6X Sand and Dust Proof Test Chamber-2

  1. When the unit is started, the air, water and drain in the box, pipelines and equipment are pumped out to create a certain vacuum to speed up the startup and avoid air and water shock. During normal operation, the vacuum system is used to pump out gas and water in time to maintain the vacuum state and improve the circulation efficiency.

IEC60529 IP5X IP6X Sand and Dust Proof Test Chamber-3

Technical parameters of sand and dust test chamber:

Model BND-IP56X -125L BND-IP56X -500L BND-IP56X -1000L BND-IP56X -1500LA BND-IP56X -1500LB BND-IP56X -1500LS
Internal dimension

(Length*Depth*Height) mm

 500*500* 500 800*800* 800 1000*1000* 1000 1000*1000* 1500 1000*1500* 1000 1500*1000* 1000
External dimension (L*D*H) mm L950×D720×H1500 L1250×D1020×H1770 L1450×D1220×H1970 L1450*D1220*H1970 L1450*D1720*H1970 L2050*D1220*H1970
Testing Temp RT+10~70℃(should be declare when order)
Humidity.Range 45%~75%（can’t display）
Mess diameter 50um
Wire spacing 75um
talc powder quantity 2～4kg/m
type of testing dust dry talc powder
falling dust Free fall
Testing time 0-999 H (adjust)
time of vibration 0-999H(adjust)
timing accuracy ±1 s
External material A3 steel with powder coating
Internal material SUS304stainless steel plate
gate structure the door with a big window, and equipped with dust scraper
protective device 0-999/H（Adjust)
vacuum degree 0—10Kpa（Adjust)
speed of evacuation 0-2400L/H（Adjust） 0-4800 L/H（Adjust） 0-6000 L/H（Adjust）） 0-6000 L/H（Adjust））
Power supply（V） AC220V 380V
Power（KW） 1KW 1.5KW 2.0KW 3.5kw
Standard IEC60529:1989+A1:1999、GB4208、GB7000.（IP5X、IP6X)
