High-Speed Drop Mechanical Shock Test Machine

Brand: SZBONAD

Product Number: BND-MS

The high-speed drop mechanical shock test machine is designed to simulate the shock waves and impact energy that parts, finished products, or packages may encounter during use and transportation. This machine helps determine the functional reliability, structural integrity, and overall impact resistance of products under various impact environments. It also assesses the protective capabilities of packaging. The machine finds extensive applications in industries such as aerospace, shipbuilding, military, automotive, consumer electronics, and more.

Mechanical Shock Tester – BONAD Shock Test Machine

Our high-speed drop mechanical shock test machine can conduct impact tests using waveforms like half-sine wave, sawtooth wave, trapezoidal wave, etc. The test piece is mounted on a working platform and elevated to a specified height under the guidance of a vertical precision guide rod. Upon impact, the required peak acceleration and pulse duration are achieved with the assistance of a waveform generator located at the base. Different specifications of waveform generators can be easily replaced manually.

Standards:

MIL-STD-202F
IEC-68-2-27
MIL-STD-883E
MIL-STD-810F
GJB150
ISTA
UL

Application:

The High-Speed Drop Mechanical Shock Test Machine is primarily used for shock resistance tests in various fields including electronic products, aerospace, ships, military industry, automotive parts, transportation, and more. The machine is capable of performing half-sine wave shock tests with the appropriate waveform generator.

Features:

Programmable Waveform Generation: By replacing the programmer, half-sine shock pulses can be generated to produce the desired pulse duration.
Automatic Rebound Brake Mechanism: Ensures precise control over rebound braking.
High Rigidity Workbench: Offers high reproducibility for consistent test results.
Shockproof Base & Soundproof Frame: Minimizes noise and vibration during operation.

Technical parameters:

Equipment model	BND-MS200	BND-MS350	BND-MS500	BND-MS700	BND-MS750	BND-MS800	BND-MS900	BND-MS1000
Working platform	200x250mm	350x350mm	500x500mm	700x700mm	750x750mm	800x800mm	900x900mm	1000x1000mm
Maximum load	10kg	25kg	50kg	100kg	200kg	300kg	500kg	1000kg
Peak acceleration	20-2000G	20-1000G	20-650G	20-600G	20-500G	20-350G	20-300G	20-300G
Pulse duration	0.5-30ms	0.8-30ms	1.5-30ms	2-30ms	2.5-30ms	3-30ms	3.5-30ms	4-30ms
Input channel	2 channels
Sampling frequency	192KHz
Input form	Voltage, charge
Voltage range	-10V–+10V
Coupling method	AC, DC, ICP
Impact waveform	Half-sine
Communication interface	USB2.0
Supported standards	National standard, national military standard, US military standard, user-defined standard
Operating system	Microsoft Windows7/10
Output method	Charge type
Power supply	Single-phase 220V±10%
Compressed air	0.5-0.8Mpa
